Name: 120/240 VAC 100 A QBH Circuit Breaker 2 Poles Bolt-On
SKU: CM9UY 1334118
Availability: InStock

Sale!

120/240 VAC 100 A QBH Circuit Breaker 2 Poles Bolt-On

Original price was: $229.00.Current price is: $96.99.

SKU: CM9UY 1334118 Categories: Breaker Panels, Breakers and Fuses, Electrical Tag: CUTLER-HAMMER

Experience the Best Quality
Your happiness, our mission.
Shop with Peace of Mind
Quality You Can Trust

QBH type circuit breaker with voltage rating of 120/240 VAC and current rating of 100 A. Has 2 poles. Bolt-on styled mounting, has 10,000 A interrupting current rating of. Wire size Range is #10 – 2 CU, #10 – 1 AL. Suitable for load centers, lighting and distribution panel boards, and meter centers. Designed to fit the classic CEB, Sylvania or Commander Electric design bolt-on load centers. Internal common trip mechanism on two pole circuit breakers. Each breaker is electronically calibrated for 40°C. Compression moulded housing and handle for durability and service.

QBH type bolt-on breakers fit panels manufactured by C.E.B., Sylvania and Commander (B/BC)
Protects: 1 x 2 pole 100Amp

Width Measurement	1-1/2-in
Number of Poles	2
Surge Protection	No
Series Name	Type QBH
Series	Type QBH
Power Capacity	100-amp
Plug-On Neutral	No
Phase	Single phase (120/240)
Interrupting Amp Listing(Amps)	10000
UL Safety Listing	Yes
Ground Fault Protection	No self test
ETL Safety Listing	No
CSA Safety Listing	Yes
Circuit Breaker Voltage	240
Circuit Breaker Type	Main
Circuit Breaker Size	1.5"wide
Amps(Amps)	100
Type	Main
